Power Query - The M Language

Recently I had the opportunity to write a Custom Connector for Power BI and come across something I didn't expect. To build a Connector you use Power Query also known as the M formula language. Power Query was designed to build data transformation pipelines, focusing on repeatable importing and manipulations of tables.

A core capability of Power Query is to filter and combine, that is, to mash-up data from one or more of a rich collection of supported data sources.

But what I didn't expect is that Power Query is a lazy functional programming language. The documentation describes it as "a functional, case sensitive language similar to F#". So not only does Power BI include a programming language it's also a functional programming language! Although if I had to describe it, I'd say it's more of a simplified cross between JavaScript and Haskell. Curious? Well then, let's take a quick look at what Power Query looks like, and some of its features.

The first thing you might notice about Power Query is that it's almost entirely expression-based. Every function is comprised of a single expression.

Function = () => "Hello"

Function() // returns "Hello"

Here we have a global variable called Function which contains a function which returns "hello". All functions are lambdas.

One of the most common building blocks is the let expression, which lets you build up more complex functions using variables.

let
   hello = "Hello",
   world = "World"
in
   hello & " " & world & "!"

If you're not familiar with the let syntax it's quite common in expression-based functional languages. A let expression allows you to define and bind other expressions for use in the in clause. You can read it like, let these "names" be bound to these "values" in this "expression".

Let's look at a more complex function. The function below makes a web request to a given URL and returns the result as JSON.

Fetch = (url as text) as record =>
    let
        accessToken = Extension.CurrentCredential()[access_token],
        authHeader = "Bearer " & accessToken,
        response =
            Web.Contents(url, [
                ManualCredentials = true,
                Headers = [ Authorization = authHeader]
            ])
    in
        Json.Document(response);

There are a few things going on in this function but one of the interesting things to point out are the two main types you see in Power Query, apart from tables of course. These are lists and records, and the interesting bit is that the symbols are opposite to what you might expect if coming from most other languages.

Lists are defined using braces {} and records are defined using square brackets [], the exact opposite of JavaScript or FSharp.

list = { 1, 2, 3}

record = [
    Property = true,
    AnotherProperty = "Hello"
]

Accessing a property is also a little different and also uses [].

value = record[Property]

In the Fetch function above you can see the access_token property being used via the credentials record.

Extension.CurrentCredential()[access_token]

Briefly, on types, the language is dynamic with optional types and can also be extended with custom metadata. Below the function starts without any types and you can see how the code changes as I add more type information.

(url) => ...expression

(url as text) => ...expression

(url as text) as record => ...expression

(url as text) as record meta [ Documentation.Name = "My Record Type" ] => ...expression

Now, I've saved the best until last. One of the most powerful features of Power Query is that it's lazy. Take for example the following code.

let
    pets = {
        Fetch("https://api.service.com/dogs"),
        Fetch("https://api.service.com/cats")
    }
in
    pets{0}

In this expression, we have a list of pets which contains the result of some API calls to a web service. However, only the first element of the array is ever accessed and because Power Query is lazy the second fetch will never actually be evaluated. In a custom connector, this could be used to access a paged rest API in order to import a table. And because evaluation is lazy using the standard take function will only fetch the pages that are needed are fetched.

It's exciting to see functional programming, especially a language as interesting as Power Query, popping up in the mainstream. I had a blast learning about Power Query and I learnt so much along the way. If you're interested in trying out a functional first language, whatever it may be, I encourage you, now is the time to check one out!
